MP Flex

MP Flex

MP Flex: Technical Features

lift TYPE

Gearless adaptable to any space

OUTSTANDING IN

Adapting to any space

CAPACITY

2 – 13 People

SPEED

1.0 – 1.6  m/s

STOPS no.

32 maximum

BUILDING IMPLICATION

Minimum

MP Flex: Características Técnicas

lift TYPE

Gearless adaptable to any space

OUTSTANDING IN

Adapting to any space

CAPACITY

2 – 13 People

SPEED

1.0 – 1.6  m/s

STOPS no.

32 maximum

BUILDING IMPLICATION

Minimum

MP Flex is a flexible solution for buildings without a lift which require very small pits and little headroom. It is also compatible with self-supporting modular structures.

The XL car option offers the largest cabin dimension, being ideal for the complete replacement of hydraulic lifts. The MINI option is the most compact solution overall, offering more cabin surface than the standard model with the smallest possible pit.

RECOMMENDED FOR THE FOLLOWING BUILDINGS TYPES

Residential

Hotel

Mall

Transport and public buildings

Residential

Mall

Hotel

Transport and
public buildings

Energy Efficiency and Commitment to the Environment

Level A certification in the VDI energy classification thanks to its LED car lighting, stand by controller shutdown and its gearless low consumption technology. Almost 95% percentage of recoverability and recyclability (LCA)

Peace of mind for users

An automatic rescue system is included as standard, meaning peace of mind for users. As it is a connected lift, it is able to relay real-time information on its use and status. This takes preventive maintenance to a whole new level and paves the way for a new generation of services.

Highly versatile and easy to install

This is the perfect solution for non-standard shafts and replacing hydraulic lifts. It can be installed in buildings with very small pits and shafts, and where there is very little headroom.

The wide cabin version (XL) offers more passengers in the same space. The MINI version offers the most compact solution with the smallest possible pit. They allow up to triple access.

Aesthetics. A wide range of finishes.

With a wide range of car finishes, this is the perfect solution for panoramic lifts with only one opaque wall

Here’s the technical documentation you need

DRAWINGS AND DIMENSIONS

EN 81-20/50
EN 81-1/2

DRAWINGS AND DIMENSIONS

EN 81-20/50
EN 81-1/2

Do you have a question about something you’ve seen in our documents?

JUST LET US KNOW AND WE’LL GET RIGHT BACK TO YOU

Optional standards

EN 81-21

Existing buildings.

EN 81-70

Accessibility to lifts for persons.

EN 81-71

Vandal resistant lifts.

EN 81-72

Firefighters lifts.

EN 81-73

Behaviour of lifts in the event of fire.

FOR OTHER STANDARDS, PLEASE ASK
